Product Introduction
SP-3020ASF-H/M
Electronic Pattern Sewing Machine
- SP-3020ASF-H
- SP-3020ASF-M
Characters
- Touch screen panel
- Oil-free needle bar
- Clean sewing
- Simple operation, easy &accurate positioning
- Unique upper thread catching device
- New pulling thread-slacking device ( National Patent)
- It is suitable for shoes ,bags and cuff of t-shirts ,which improves productivity by 100% -300%.
Three positional feeding plate(optional)
- Applied for layers of combined model plates in various kinds .
- Clamping and sewing simultaneously, the machine reduces the time wasted on waiting and improves efficiency.
- Automatic positioning and model plate scanning before start .
- Successive and automatic program changing .
- Sewing layers of combined patterns in same fabric ,this device reduces the producing period by using same table&stand.
-
Model
Line
Highest sewing speed
Sewing area
Cloth feeding mode
Stitch Length
Maximum stitch amount
Storage amount of stitches
Presser foot drive method
Press foot height
2- step presser foot
Big foot presser height
Big foot presser method
Rising amount of intermittent foot presser
Stroke by intermittent presser foot
Thread Wiper
Cutting device
Customer program amount
Recyle programme No.
Motor
Weight
Power
Air pressure
-
SP-3020ASF-HSing-needle flat seam2,800 rpmMax.300×200mmIntermittent feeding（Pulse motor drive mode）0.05-12.7mm20,000 needles/1 pattern500000 stitch can be stored in build-inmomeryPneumaticMax. 30mmAll-in-one presser footMax. 30mmAll-in-one presser foot22mm0 or 2-10mm（Factory defaults：3mm）Standard facilityStandard facility509AC servomotor 550WHead：About 150kgSingle phase100~120V、200~240V、3-phase 200~240V、380~415V、350V0.5Mpa、1.8L/min
-
SP-3020ASF-MSing-needle flat seam2,800 rpmMax.300×200mmIntermittent feeding（Pulse motor drive mode）0.05-12.7mm20,000 needles/1 pattern500000 stitch can be stored in build-inmomeryPneumaticMax. 30mmAll-in-one presser footMax. 30mmAll-in-one presser foot22mm0 or 2-10mm（Factory defaults：3mm）Standard facilityStandard facility509AC servomotor 550WHead：About 150kgSingle phase100~120V、200~240V、3-phase 200~240V、380~415V、350V0.5Mpa、1.8L/min
